The Bell & Gossett 1535 foot-mounted, end-suction, close-coupled pumps are available in 1” through 1-1/2” sizes. There are several motor sizes 1/3 to 5 HP at 3500 RPM and are available in bronze-fitted construction with flows to 240 GPM at 115 feet. This back-pullout pump offers ease of service in a close-coupled design. The pump can be mounted vertically or horizontally to provide maximum flexibility. Ball bearing design and standard internally flushed mechanical seal provide long, dependable service.
|
SERIES:
|
1535
|
|
PART NUMBER:
|
168042
|
|
MODEL:
|
3510T
|
|
CONNECTION TYPE:
|
1-1/2″ x 2″
|
|
IMPELLER DIAMETER:
|
4-7/16″
|
|
MATERIAL:
|
Cast Iron
|
|
MOTOR PHASE:
|
Three
|
|
HORSEPOWER:
|
3
|
|
RPM:
|
3500
|
|
HERTZ:
|
60Hz
|
|
VOLTAGE:
|
208-230/460v
|
|
MAX TEMPERATURE:
|
225
|
