179212LF Bell & Gossett e9053S-ECM Motor Inline Pump 230V, 1.25AAB, 5″ Impeller Diameter, .50 HP, 230V Single Phase with 1.25″ flange size. The close-coupled e-90 centrifugal in-line pump is designed specifically for HVAC markets. It is now also available with highly efficient optional ECM motors as stock part numbers. These variable speed motors with motor-mounted interface adjust motor speed to match flow and head requirements, thus substantially reducing power consumption. The user interface allows for manual adjustment or controlled remotely via 10 VDC input/output. Series e-90 pumps with ECM motors are not only more efficient than their standard induction motor counterparts, they are quieter, vibrate less, and have a lower total lifetime cost of ownership.
Materials Of Construction/Features:
- BRONZE FITTED CONSTRUCTION
- 1765 RPM ODP, ELECTRONICALLY COMMUTATED MOTOR/PERMANENT MAGNET INTERNAL SELF-FLUSHING MECHANICAL SEAL
- EPR/CARBON/SILICON CARBIDE (-10°F TO 250°F)
- 175 PSI (12 bar) MAXIMUM WORKING PRESSURE
Available in pipe sizes from 1” to 3”, with single phase ECM motor sizes from ½ HP to 1 HP at 1765 RPM. Available in bronze-fitted construction. Flows to 225 GPM and heads up to 30 feet.
|
Manufacturer:
|
Bell & Gossett
|
|
Part Number:
|
179212LF
|
|
Model Number:
|
e9053S-ECM
|
|
Pump Size:
|
1.25AAB
|
|
Horsepower:
|
1/2
|
|
Impeller Diameter (in):
|
5″
|
|
Voltage:
|
230V
|
|
Phase:
|
1
|
|
Hz:
|
50/60
|
|
Min RPM:
|
350
|
|
Max RPM:
|
1765
|
|
Flange Size:
|
1.25″
|
