1EF159LF Bell & Gossett Be651S-ECM AB Series e-60 Pump 1/2 HP All Bronze Construction with 1.25″ Flange Size, Pump Size 1.25×1.25×5.25, 1/2HP, 115/1/50-60/1725. The Bell & Gossett Series e-60 ECM is a three-piece centrifugal in-line pump designed for HVAC and potable water, featuring the high efficiency and variable speed capability of ECM technology. Series e-60 ECM pumps come with an Electronically Commutated Motor, which features a simple user interface that allows for manual speed adjustment or automatic speed control via 10VDC input signal. Series e-60 ECM pumps are more efficient, quieter, and have a lower total cost of ownership than their standard induction motor counterparts over the lifetime of the pumps.
Ease of Selection: Series e-60 pumps come in 9 sizes, with 144 available stock models and many more Built-to-Order configurations. Both stock and BTO pumps are easily selectable using B&G pump selection and e-order software.
Simple, Versatile Installation: The Series e-60 mounts directly to system piping by its bolted flange connections, offering design flexibility and saving valuable floor space. As a replacement pump, the Series e-60 is a perfect drop-in solution, as flange- to-flange and intake/suction dimensions are identical to equivalent legacy Series 60 models — and even some competitors’ pumps.
Robust Design: The Series e-60 employs high quality components for smooth performance and long pump life. The pumps permanently lubricated rotating bearings come fully enclosed in Polyrex grease for true maintenance-free operation. The unitized mechanical seal offers better performance and longer life.
Ease of Service: Three-piece design allows for minimally invasive service. The motor, coupler, seal and impeller can all be repaired or replaced without removing the pump from its piping. The one-piece seal simplifies seal replacement, eliminating the clumsy task of assembling difficult seal components to the shaft.
Series e-60 ECM:
• Variable Speeds from 300-1725 RPM
• On-board dial for manual speed control
• 0-10V DC signal input for automatic control
• Quieter operation than standard induction motors • ECM up to 82% efficient at constant speed
|
Manufacturer:
|
Bell & Gossett
|
|
Series:
|
e-60 ECM
|
|
Model:
|
Be651S-ECM BF
|
|
Materials Of Construction:
|
All Bronze
|
|
Part Number:
|
1EF159LF
|
|
Pump Size:
|
1.25×1.25×5.25
|
|
Impeller Diameter (in.):
|
5.000
|
|
Flange Size:
|
1.25″
|
|
Motor HP:
|
1/2
|
|
RPM:
|
1725
|
|
Phase:
|
Single 115v
|
|
Working Pressure:
|
175 PSI Max
|
|
Hertz:
|
50/60
|
|
Motor Model #:
|
SM2126
|
