Bell & Gossett e-1510 1.5BC Pump 15 HP 3525 RPM 3 Phase ODP with 9.5″ impeller. This pump features a 2″ NPT end suction and a 1-1/2″ NPT top discharge.
Bell & Gossett has redesigned the complete line of its best-in-class 1510 pump – now called the e-1510– to provide the highest overall efficiency in the end-suction market for HVAC and plumbing applications. With the largest Efficiency Island compared to other similar pumps, the e-1510 reduces electricity consumption, improves overall system performance and lowers life cycle costs.
This new and extensive efficiency profile enables users to maintain significantly higher levels of efficiency over a much wider range of operating conditions. The Series e-1510’s dramatic improvement in efficiency is the result of cutting edge computational fluid dynamics (CFD) design technology, deep hydraulic engineering expertise, and Xylem’s comprehensive knowledge of HVAC and plumbing applications. The new Bell & Gossett Series e-1510 is available in 26 sizes and a variety of configuration options that enables customization and flexibility to fit a broad range of operating conditions.
Features & Benefits
- True Back Pullout
- Internally Self-Flushing Mechanical Seal
- Computer Controlled Impeller Balancing
- Heavy Duty, Rugged Baseplate
- Solid-Foot Mounted Volute
- Center Drop-Out Spacer Coupling
- ANSI/OSHA-Compliant Coupling Gaurd
- Patented i-ALERT Condition Monitor Option
|
Manufacturer:
|
Bell & Gossett
|
|
Series:
|
Series e-1510
|
|
Model:
|
1.5BC
|
|
Connection Type:
|
Threaded
|
|
Connection Size:
|
1-1/2″ x 2″
|
|
Shaft Size:
|
1-5/8″
|
|
Impeller Diameter:
|
9-1/2″
|
|
Working Pressure:
|
175 PSI
|
|
Pump Type:
|
Centrifugal
|
|
Mounting Type:
|
Base Mounted
|
|
Construction:
|
Cast Iron
|
|
Horse Power:
|
15 HP
|
|
Motor RPM:
|
3525
|
|
Motor Phase:
|
Three
|
|
Voltage:
|
208-230/460v
|
|
Motor Enclosure:
|
ODP
|
|
Hertz:
|
60Hz
|
|
Max Temp:
|
225*F
|
|
Frame Size:
|
215T
|
