VSX-VSCS Bell & Gossett Vertical Split Case Pump Model 6x8x10-1/2B, rated for 1000 GPM, 80’ TDH, 9.25” Impeller, LHR, 40HP 1780/200/3/60 TEFC 324T EPACT NEMA Premium Efficient Motor, Unitized EPR/SiC/SiC (175 PSI – 300°F) Seal. Be sure to specify exact motor voltage requirement when placing an order. Note: ANSI 8” suction, 6” discharge companion flanges and gaskets supplied by others.
The new VSX platform retains the innovative and time-proven space saving VSC design. The VSC model has reduced your pump room footprint by up to 40% when compared to traditional split-case and vertical inline pumps. The time-proven VSC design now becomes even better within the new VSX platform. The high-efficiency VSX hydraulic design and robust construction deliver proven Bell & Gossett reliability, and the unique platform design provides complete installation versatility. Simply select your hydraulic requirements and then pick any one of three different suction and discharge flange orientations that best suit your installation requirements. In short, VSX is everything you asked for, and then some. We furnish Baldor Electric and WEG motors that meet current NEMA Premium efficiency electrical standards.
