MILLER MAXSTAR 161 S STICK WELDER (907709)
The new Miller Maxstar 161 welders now have a digital interface and feature a greater amperage range than their predecessor Maxstar 150 units. Machine setup is done in 3 easy steps – press the menu button to select your process, then hold the menu button for 1 second to access the user menu. The last step is turning the encoder to adjust your selected parameter.
The Maxstar 161 S models are not TIG capable.
New Features
• Digital meter interface
• Auto-line 120V and 240V power cords
• Pulse feature on STH models only
• Upgraded shoulder strap and handle
• Added space inside the X-Case
Quick Specs
• Stick Amperage Range: 120V – 20-90A | 240V – 20-160A
• Material Thickness: .020 – 3/16 Steel | 5/32″ Electrodes
• Duty Cycle: 120V – 30% at 90A | 240V – 20% at 160 amps
• Dims: 10.3 H x 5.6 W x 13.5 D
• Weight: 13lbs
Includes
• Maxstar 161 S power source
• 6.5ft 120V and 240V power cords
• 13ft Stick electrode holder and 25mm dinse connector
• 10ft Work clamp and 25mm dinse connector
• Shoulder strap and handle
| Brand | Miller |
|---|---|
| SKU | IMIL20160028 |
| MPN | MIL907709 |
| Mfgs MPN | 907709 |
| UPC | 715959645560 |
| Prop65 | Yes |
| Material | Mild Steel, Stainless Steel |
| Process | Stick |
| Max Amperage Output | 160 |
| Usage | Home/Hobby, Industrial, Light Industrial |
| Phase | Single Phase |
| Manufacturer’s Warranty | 3 Years |
| Polarity | DC |
| Duty Cycle | 20% |
| Duty Cycle | 20% at 160A |
| Portability | 13 lbs |
| Skill Level | Beginner, Weekend Warrior, Career Welder |
| Input Voltage | 120, 240 |
| Discontinued Product | No |
