1615D3E1-1/3HP-3PH, 200-230/460/60/3 Taco Stainless Steel 1/3HP 3PH Pump With 1.5″ Flange. Stainless Steel Casing (non NSF). Stainless Steel Casing, Bracket, Stainless Steel Impeller, Alloy Shaft w/Cupronickel Shaft Sleeve, Ceramic Seat, Carbon Rotor, EPT Rubber, 250 Deg F, Ball Bearing Cartridge with Companion Flanges Are Included In 1-1/2″. Three Phase Motors: 1750 RPM, Standard efficient, 200-230/460/60/3, ODP Motor.
Taco 1600 Series In-Line Pumps feature a replaceable, permanently-lubricated bearing cartridge. The exclusive 1600 cool-bearing cartridge design isolates the bearing from the effects of system temperatures to greatly extend bearing life. A standard bearing design also means that a single bearing cartridge can be used to service the entire line, making servicing a snap. Taco 1600 Series pumps are available in 15 models ranging in performance capacity from 10 GPM to 235 GPM with head capacities up to 68 ft.
|
Brand:
|
Taco
|
|
Model:
|
1615D3E1-1/3HP-3PH
|
|
Series:
|
1600
|
|
Material:
|
Stainless Steel
|
|
Max Pressure (PSI):
|
175 psi
|
|
Horse Power:
|
1/3 hp
|
|
Connection Size:
|
1-1/2″
|
|
Phase:
|
Three
|
|
RPM:
|
1750
|
|
Connection:
|
Flanged
|
|
Voltage:
|
208-230/460
|
|
Hertz:
|
60
|
|
Max Temperature:
|
250F
|
|
Working Pressure:
|
175 psi
|
