1635D3E3 Taco Stainless Steel Pump 1-1/2HP 1PH. 1635D3E3-1-1/2HP-1PH Taco Stainless Steel 1600 Series Pump With 2″ Flange. Stainless Steel Casing (non NSF). Stainless Steel Casing, Bracket, Stainless Steel Impeller, Alloy Shaft w/Cupronickel Shaft Sleeve, Ceramic Seat, Carbon Rotor, EPT Rubber, 250 Deg F, Ball Bearing Cartridge with Companion Flanges. Single Phase Motors: 1750 RPM, Standard efficient, 115/60/1, ODP Motor.
Taco 1600 Series In-Line Pumps feature a replaceable, permanently-lubricated bearing cartridge. The exclusive 1600 cool-bearing cartridge design isolates the bearing from the effects of system temperatures to greatly extend bearing life. A standard bearing design also means that a single bearing cartridge can be used to service the entire line, making servicing a snap. Taco 1600 Series pumps are available in 15 models ranging in performance capacity from 10 GPM to 235 GPM with head capacities up to 68 ft.
|
Brand:
|
Taco
|
|
Model:
|
1635D3E3
|
|
Series:
|
1600
|
|
Material:
|
Stainless Steel
|
|
Horse Power:
|
1-1/2 hp
|
|
Connection Size:
|
2″
|
|
Phase:
|
Single
|
|
RPM:
|
1750
|
|
Connection:
|
Flanged
|
|
Voltage:
|
115/60/1
|
|
Hertz:
|
60hz
|
|
Max Temperature:
|
250F
|
|
Working Pressure:
|
175 psi
|
