VR30H-SF Taco 00e VR Series Stainless Steel 3″ ECM Hi-EFF High Head Circulator. The Taco 00e Series pump is a Web-enabled, wet rotor, variable speed commercial pumps for chilled and hot water applications. A convergence of efficiency, simplicity and technology within this new generation of wet rotor circulators. The 00e (VR15 – VR30) are versatile web-enabled, wet rotor, variable speed line of commercial pumps for chilled and hot water applications. Internet access and settings make installation, setup and service easy. The ECM motor saves up to 85% of the electrical energy compared to conventional pumps. Multiple operating modes make this pump a perfect choice for most applications
The Taco 00e VR series are ECM high-efficiency, wet-rotor, self-sensing commercial circulators ideal for HVAC and potable water applications. The wide range of models with Low, Medium, or High head options provide differential head pressures up to 65 ft. and flow ranges up to 320 GPM. BMS communication with Modbus, BACnet, 0-10Vdc, and PWM come standard while high-efficiency ECM technology reduces power consumption up to 85%. The stainless steel models are NSF 61 & 372 domestic and commercial hot rated.
- Intuitive user interface with real-time feedback
- Constant speed, constant pressure, proportional pressure, and activeADAPT®; self-adjusting proportional pressure
- BMS communication; Modbus, BACnet, 0-10Vdc, PWM
- Parallel pump control; cascading, auto-rotate & main/ standby
- Dry run protection
- Line surge protection
- Current limit protection
- Non-overloading ECM high-efficiency offers smart protection with integrated soft-start technology. Single phase voltage range 110-240 volts up to 800 watts, single phase 200-240 volts above 800 watts.
|
Brand:
|
Taco
|
|
Model:
|
VR30H-SF
|
|
Material:
|
Stainless Steel
|
|
Max Shut Off Head:
|
62 Feet
|
|
Max Flow:
|
320 USGPM
|
|
Water Temperature Range:
|
14 to 230*F (-10 to 110*C)
|
|
Ambient Temperature Range:
|
32 to 104*F (0 to 40*C)
|
|
Ambient Humidity:
|
Less than 95% RH
|
|
Max Pressure (PSI):
|
175 psi
|
|
Power Consumption (HP):
|
2.1 HP
|
|
Power Consumption (W):
|
1550 W
|
|
Voltage (All Single Phase):
|
200-240
|
|
24 Volt Supply Outlet:
|
Max current up to 100mA, Output Voltage +/- 20% of 24 Volts, Output Ripple under 1 Volt
|
|
Connection Size:
|
3″
|
|
Connection:
|
Flanged
|
