Brand: Helix
Manufacturer’s Part Number: HEXIFSCFMAYE01MLCA
Part Type: Front Suspension Packages
Product Line: Helix CornerKiller IFS Suspension Packages
Summit Racing Part Number: HLI-9078600
Wheel Bolt Pattern: 5 x 4 3/4 in.
Crossmember Included: Yes
Crossmember Material: Steel
Crossmember Color: Natural
Welding Required: Yes
Front Spindles Included: Yes
Spindle Material: Cast iron
Spindle Finish: Natural
Upper Control Arms Included: Yes
Lower Control Arms Included: Yes
Control Arm Style: Tubular
Control Arm Material: Steel
Control Arm Color: Black
Upper Ball Joints Included: Yes
Lower Ball Joints Included: Yes
Rack and Pinion Included: Yes
Steering Rack Type: Manual
Rack Material: Steel
Rack Color: Polished
Shocks Included: No
Shock Type: Coilover
Coilover Springs Included: Yes
Spring Finish: Chrome
Disc Brake Kit Included: Yes
Front Rotor Included: Yes
Front Rotor Style: Cross-drilled/Slotted surface
Front Rotor Construction: Vented
Front Rotor Diameter: 11.00 in./279.40mm
Front Caliper Included: Yes
Front Caliper Piston Quantity: One
Front Caliper Material: Cast iron
Front Caliper Color: Natural
Brake Pads Included: Yes
Sway Bar Included: No
Center Link Included: No
King Pins Included: No
King Pin Bearings Included: No
Pitman Arm Included: No
Idler Arm Included: No
Tie Rod Sleeves Included: No
Inner Tie Rod Ends Included: Yes
Outer Tie Rod Ends Included: Yes
Quantity: Sold as a kit.
Notes: Steering system is designed for left hand drive vehicles.
Helix CornerKiller IFS front suspension will revolutionize your suspension and give your car or truck the ride and handling it deserves. Each front suspension is specially designed to give your classic ride modern handling and stopping power by updating all of the critical parts. Helix starts with precision-made components that are designed to work together. Tubular control arms provide the adjustability you need to setup the suspension for your car, while your choice of standard to 2 in. drop spindles help you customize the stance. Topping off the spindles is a set of 11 in. disc brakes to provide extra stopping power. Rack and pinion steering is provided by either power assist or manual racks. Finally choose between coilovers for maximum handling and a static stance or air struts for the ultimate in ride height control and ride quality. Bring your classic ride into modern days with a Helix CornerKiller IFS front suspension package.
